How to sync a local file server with Office 365 / SharePoint Online / OD4B?



"We couldn't sync this library." in SharePoint Online is a typical error message to receive if you try to sync document libraries to a local drive using the OneDrive for Business client. This could have many reasons. See below about how to solve all of it using the Layer2 Cloud Connector.



Office 365 File Sync Issues Solved By Layer2 Cloud Connector 600



When you are moving to the Microsoft Office 365 and SharePoint Online cloud, there are a lot of reasons to keep your local file system, for example:

  • To quickly access files with non cloud-based applications or legacy systems
  • To work offline and with increased performance and without internet connectivity
  • For integration into local business processes
  • For compliance reasons
  • As some kind of local backup (or to manage "cloud" backup with common backup software)s some kind of local backup (or to manage "cloud" backup with common backup software)



But you don't have to miss the benefits of the cloud, like web based search, versioning, change notifications, workflows, mobile access etc. Setup a hybrid scenario:



You can synchronize selected parts of your local file system or server share with a SharePoint, Office 365 or OneDrive for Business document library in the cloud.



This article shows how this works step-by-step with the Layer2 Cloud Connector. The product can close some gaps and solve many issues that still exists with the Microsoft out-of-the-box offerings.



Office 365: We couldn't sync this library error

Fig. If you try to sync SharePoint Online document libraries using the OneDrive for Business client you will often receive an error message like "We couldn't sync this library.". This can have many reasons. See below about how to solve all of it.



tabelle-1



* Depending on configuration and amount of changes - but no hard 5.000 / 25.000 items limit as out-of-the-box. Please edit your SharePoint views to still be able to navigate your files: Remove all sorting, filtering, grouping. Also set to flat view in the folder section in case you have folders with more than 5.000 files. You can make use of SharePoint search or managed metadata to find your files without any restrictions. The "folder" parameter in connection string is not supported above the list view threshold (as it is implemented as a filter by SharePoint).



** Take a look here for supported systems and applications.



Now let's setup a sample connection to sync a selected file share directory one-way to SharePoint Online.

1. Select parts of your local file system to sync with Office 365



​Assuming you have a local file system like this, e.g. some folders at C: drive:



How to sync local files

Fig. Local File System to synchronize with the Microsoft Office 365 cloud - but also works for server shares.





You first have to setup the connection definition in the Cloud Connector, for example "FileSystem to Cloud":



Example of connection definition for filesystem to cloud replication

Fig. Connection definition for Filesystem to cloud replication, unidirectional in this example.





Please note:



  • There is a bi-directional option available to sync back changes done online in the SharePoint library back to the local file server.
  • There is an overwrite option to use for cleanup, if your library already contains some data.
  • Do not enable scheduling at this point. Please enable scheduling later on, when all tests are passed.



As a next step you have to setup the data source of the newly created connection as follows.

2. Define your local file system as data source for Office 365 replication



Confirguration Example

Fig. Example file system data source configured for replication to Office 365.





Please note:



  • Select the Layer2 FileSystem Provider as Data Provider.
  • Enter the source directory (root) "Test2" with the notation Directory=C:\Test2 or similar as connection string. You can also use mapped network drives, e.g. K:\. UNC notation supported as well, e.g. \\myserver\myshare. Please make sure that the current account (for Connection Manager) and service account (for the background update) has appropriate rights to access the shared drive. Note that Windows Services often run with local accounts and have no access to shares by default. You have to modify the accounts and / or access rights for this.
  • There are additional options available in connection string for non-recursive replication or to filter specific file types:
  • Directory: Root path where the files will be read from (mandatory).
  • UserId / Password: Optional credentials to connect to target path. Aliases are User, UserId, User Id and Password, pass, pwd.
  • FilenameFilter: Optional search pattern for filtering files by name or extension. Parameter accept standard windows file search pattern like *, ?. Aliases are FilenameFilter, FileNameFilter, filenamefilter. (Note that you can only set one filter pattern for this parameter.)

    Examples:

    *jpg = file extensions
    Layer2* = Files which begins with Layer2
    *Layer2* = Files that contain Layer2
  • SQL-like query is supported to include or exclude folders and files to / from sync by name (including like or wildcards), type, size and date.

3. Define a SharePoint library in Office 365 as data destination for your file system



Now you can create a SharePoint library in the clound, e.g. "FileSystem" in this sample. As a next step you have to setup the data destination of the newly created connection as follows.



Example data source

Fig. Example data source to replicate a part of a file system to Office 365





Please note:

  • You have to select the Layer2 SharePoint CSOM Provider to communicate with the cloud using web services.
  • Setup the connection string for example as:
    Url=https://mydomain.sharepoint.com/sites/mysite/; List=myList;   Authentication=Office365; [email protected]; Pass=myPassword
  • There are other authentication methods available, if required. See User's Manual for this.
  • The URL goes to the site that hosts the library.

4. Setup field mapping for file system metadata



To map the file system files and metadata to your SharePoint library you can simply use the "Auto-Mapping" feature or map the fields manually - as shown below.



Field mapping example for file sync to sharepoint libraryFig. Field mapping example to sync file system meta data to a SharePoint library.





Please note:

  • You can generally map file system metadata as Created / Modified to the corresponding SharePoint fields. But note: Writing to SharePoint system fields (Modified requires specific access rights and can cause replication issues. We strongly advise to map such fields to custom columns, like FSCreated, FSModified, etc.
    The custom fields must be created before mapping.
  • Please be careful when mapping author/editor data to the SharePoint metadata fields. In some cases, the user tokens are not the same between file system and the cloud accounts, and may lead to warning about missing users in SharePoint.
  • If you can't find some list columns in mapping, they are not exposed in the view you are using for sync. If you don't give any view in connection string, no view is used and it pulls ALL columns for that library. Better to use specific view for sync. Please add the columns needed there. Remove ANY sorting, grouping, filtering to overcome the list view threshold.
  • Office document metadata is propagated by SharePoint automatically in case the columns exist with the same column name. For example, an Author column is populated with the content of an Author metadata field automatically by SharePoint. You don't have to assign such kind of metadata in the field mapping section.
  • If using bi-directional syncing, please note the conflict resolution mode (in the Mappings section). Please select depending on your requirements. For more information about the different modes, see the User Documentation under "Conflict Resolution".
  • You can also sync your file system with SharePoint lists to only add metadata and backlinks - not the files itself.

5. Access your local files via Office 365 from everywhere



​When all connection settings are done and verified successfully, go back to the configuration settings and run the connection first time. After all files are tranferred, you can benefit from your local data replicated to the cloud.



SharePoint library of SharePointFig. Example of SharePoint library with file system content replicated.





Please note:

  • In case of errors while replicating first time, please see the log section. Increase log level for more details, if required.
  • Initial replication can take some time, depending on amount of data and bandwidth. Expect 2-4 seconds communication overhead per file plus the upload time. Note that Office 365 limits the upload (and also download) speed.
  • Later on, only changed items are replicated. This is much faster compared to the initial replication. Expect around 20-40 seconds to compare metadata per 5.000 files + upload / download time for changed files.
  • To setup automatic background replication, e.g. every 24 hours or 20 minutes go to connection settings. Be careful to set sync intervals < 20 minutes (depending on your typical sync duration).
  • Generally there should be only low CPU and memory usage during sync. Syncing large files can result in temporary higher memory usage.
  • SharePoint has different file name, type, path or size restrictions compared to the file system. Possibly you want to fix before sync. You can do manually based on our error / warning messages or use tools before to fix, like e.g. SharePrep for help. You can also try powershell:

    ls E:\CompanyData -R | ? {  ($_.FullName.Length -ge 260) -or ($_.DirectoryName.Length -ge 248) } | select FullName

    Otherwise the Cloud Connector will manage different naming conventions by itself.
  • Please note the SharePoint list view threshold above 5.000 items in a list or library. This is not an item limit - no problem with sync! Please use an usorted, unfiltered, ungrouped view for replication in connection string. This view can be executed in all cases also above 5.000 items. Please index your columns to execute more complex views. Display your library as flat file list, if required, by removing the folder option in view settings. Use managed metadata navigation, folder navigation and search within large libraries and lists without any restrictions. For best results keep the number of files per folder below 5.000.
  • To enable document properties (e.g. title, description, author, etc.) promotion to SharePoint columns please take a look here.
  • To automate the complete migration process for a large number of user home drives to OneDrive for Business by scripting (including user provisioning and other required steps) take a look here.
  • You will have all features of a native SharePoint library or list, including change notifications or workflows on external data change.



 For more information and a free download of the Layer2 Cloud Connector see here.
